Single-spindle hydraulic veneer lathe · BQ1226/15E

• Ausgelegt für — Schälen von Stämmen zu durchgehenden Furnierblättern für Sperrholz
• Model BQ1226/8E1 BQ1226/8F1 BQ1226/5 BQ1220/8 BQ1215/8A1 BQ1215/5 Diameter of rotary log（mm） Φ170-Φ800 Φ170-Φ800 125-500 170-800 170-800 125-500 Length of rotary log（mm） 2150-2700 2150-2700 2100-2700 1600-2000 1000-1500 900-1450 Thickness range of rotary veneer(mm) 0.35-3.9 0.35-3.9 0.3-3.25 0.35-4.2 0.35-4.2 0.3-3.25 Axle diameter(mm) Φ100 Φ130 100 100 85 ( 100 ) 100 Maximum revolution of clamping shaft(rpm) 0-200 0-200 53-160 160 0-160 10.5-105 Quick advance and retreat speed of cutter bed(m/min) 1.8 1.8 1.37 1.8 Main motor power(kw) 75 75 55 75 45 30 Power of electric rear angle motor 0.75 0.75 0.75 0.75 0.75 0.75 Power of fast feed motor(kw) 4 4 3 4 4 3 Hydraulic motor power(kw) 7.5 7.5 5.5 7.5 7.5 5.5 Tool bed grinding angle applicable to cutting tools 18°-22o 18°-22° 18°-20° 18°-22° 18°-22° 18°-20° Preis anfragen Frage stellen
