사양
HTK-NST-3020 · HTK-NST-3020D · HTK-RCN-3020F
| 모델 / 품번 | HTK-NST-3020 | HTK-NST-3020D | HTK-RCN-3020F |
|---|---|---|---|
| Furação Drilling Head | Opcional · Optional | Sim · Yes | Opcional · Optional |
| Automatic Labelling at Infeed | Sim · Yes | Sim · Yes | – |
| Total Power | 50,0 kW · 380 V Trifásico | 55,0 kW · 380 V Trifásico | 45,0 kW · 380 V Trifásico |
| Produção Production Capacity | 60–80 chapas/dia · panels/day | 60–80 chapas/dia · panels/day | 45–60 chapas/dia · panels/day |
| Working Area (L x W x H) | – | – | 3.050 x 2.100 x 250 mm |
| (X, Y) Speed (X, Y) | – | – | 80 m/min (servo drives 1,5 kW) |
| Main Spindle | – | – | 12 CV (9,0 kW) · 24.000 rpm · blindado, refrigeração a ar |
| Vacuum Pumps | – | – | 2x 10 CV (7,5 kW) Becker · 8 setores |
| Ferramentas Number of Tools | – | – | 16 ATC · Linear no pórtico |
| Control System | – | – | SYNTEC 63CA / NC Studio |
| Softwares Software Integration | – | – | Promob; CorteCloud; MobCloud; R-Hex; WPS; Dinabox; Gabster; TopSolid, entre outros |
| Materiais Materials | – | – | MDF, MDP, compensado, madeira maciça, PVC, acrílico, ACM, PS, alumínio, cobre, entre outros |
사양은 모델 사양서에 기재되어 있습니다. 요청하시면 미터법과 인치법 전체 데이터를 보내드립니다.
