Beam saws, SEC series
4 models · HTK-SEC-2910 · HTK-SEC-3310 · HTK-SEC-3315RL …
- Built for — ripping, crosscutting and bevel cutting of MDF, plywood and laminated panels
- Max. cutting height — 100–120 mm
- Main motor — 16.2–29.46 kW
- Scoring motor — 2.24 kW
- Scoring blade as standard — chip-free cuts on melamine and laminate
- CNC control — programs stored and repeated, no manual setup between jobs
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-SEC-2910 · HTK-SEC-3310 · HTK-SEC-3315RL · HTK-SEC-3315RLD
| Model / Stock No. | HTK-SEC-2910 | HTK-SEC-3310 | HTK-SEC-3315RL | HTK-SEC-3315RLD |
|---|---|---|---|---|
| Cutting length | 2,850 mm | 3,300 mm | 3,300 / 3,800 mm | 3,300 / 3,800 mm |
| Cutting height | 100 mm | 100 mm | 120 mm (optional 150/165 mm) | 120 mm (optional 150/165 mm) |
| Number of grippers | 8 | 10 | 10 / 12 | 10 / 12 |
| Main / scoring blade | 320 mm (optional 380) / 200 mm | 320 mm (optional 380) / 200 mm | 500 mm (optional 550) / 200 mm | 500 mm (optional 550) / 200 mm |
| Return speed | 100 / 120 m/min | 100 / 120 m/min | 120 m/min | 120 m/min |
| Carriage/Gripper Servomotors | 3 HP three-phase 380 V | – | – | – |
| Main motor | 21.7 HP three-phase 380 V | 21.7 HP three-phase 380 V | 39.5 HP (optional 50) · 4,000 rpm | 39.5 HP (optional 50) · 4,000 rpm |
| Scoring motor | 3 HP three-phase 380 V | 3 HP three-phase 380 V | 3 HP (optional 4.0) · 5,200 rpm | 3 HP (optional 4.0) · 5,200 rpm |
| Air-cushion tables | 3 independentes | 4 independentes | 4 independentes | 4 independentes |
| Loading | Manual (optional front with lifting table, or gantry with vacuum cups) | Manual (optional front with lifting table, or gantry with vacuum cups) | Rear automatic by pallet (forklift) | Rear automatic by pallet · double gripper system (double beam) |
| 3-side safety guards | optional · Optional | optional · Optional | Yes · Yes | Yes · Yes |
Specifications are published on the model spec sheet — request it and we'll send the full data.
