BSW-4025 · BSW-6045
6 models · HTK-SFT-2515 · HTK-SFT-4025 · HTK-SFT-6045 …
- Built for — saws, sliding table saws, beam saws and cnc routers
- Tooling — blade and knife sizes matched to your material
- Units — metric and imperial dimensions on the same sheet
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-SFT-2515 · HTK-SFT-4025 · HTK-SFT-6045 · SFT-3017 · SFT-3520 · SFT-3523
| Model / Stock No. | HTK-SFT-2515 | HTK-SFT-4025 | HTK-SFT-6045 | SFT-3017 | SFT-3520 | SFT-3523 |
|---|---|---|---|---|---|---|
| Wheel Diameter | 250 mm | 400 mm | 600 mm | 300 mm | 350 mm | 350 mm |
| Throat Width | 250 mm | 370 mm | 570 mm | 305 mm | 330 mm | 340 mm |
| Cutting Height | 152 mm | 250 mm | 450 mm | 165 mm | 200 mm | 225 mm |
| Blade Speeds | 400 e 800 m/min | 900 m/min | 800 m/min | 370 e 900 m/min | 900 m/min | 370 e 1.000 m/min |
| Table (45° tilting) | 360 x 320 mm | 470 x 470 mm | 560 x 560 mm | 480 x 390 mm | 520 x 450 mm | 545 x 515 mm |
| Band Blade | 1,82 m x 3–13 mm | 2,91 m x 6–25 mm | 4,00 m x 10–25 mm | 2,24 m x 3–19 mm | 2,68 m x 6–19 mm | 2,56 m x 6–25 mm |
| Dust Outlet | 1x 4" (100 mm) | – | – | – | – | – |
| Main Motor | 400 W Monofásico 110/220 V | 2,0 CV Monofásico 220 V ou Trifásico 220/380 V | 2,0 CV Monofásico 220 V ou Trifásico 220/380 V | 1.000 W Monofásico 220 V | 1,5 CV Monofásico 220 V | 2,0 CV Monofásico 220 V |
Specifications are published on the model spec sheet — request it and we'll send the full data including metric and imperial units.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
Get a quote
