HTK-AFI-2720 · HTK-AFI-257
2 models · HTK-AFI-2720 · HTK-AFI-257
- Built for — planing, moulding, sanding, pressing and finishing in joinery and furniture production
- Total weight — 200–248 kg
- Tooling — blade and knife sizes matched to your material
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-AFI-2720 · HTK-AFI-257
| Model / Stock No. | HTK-AFI-2720 | HTK-AFI-257 |
|---|---|---|
| Milling Cutter Dia. x Thickness | 200 × 180 mm | – |
| Max. straight knife length | 250 mm | 650 mm |
| Circular Sawblade Diameter | ø120-ø500 mm | – |
| Router Cutter | 13 mm | – |
| Grinding wheel speed | 3000-5000 rpm | 2850 rpm |
| Main motor power | 0.75 kW | 1.1 kW |
| Overall dimensions | 850 x | 1140 × 588 × 1203 mm |
| Net weight | 200 kg | 248 kg |
| Configuration | 2 functions | 3 functions |
| Functions | Panel saw + shaper | Surface planer + thicknesser + mortiser |
| Sharpening Blade Angle | – | 34°-42° |
| Emery Wheel Dimensions | – | BW125 × 45 × 32 |
Specifications are published on the model spec sheet — request it and we'll send the full data.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
