JPB-333
3 models · HTK-DSP-1215C · HTK-DSP-1820 · HTK-DSP-9020C
- Built for — planers, moulders, sanders, presses and finishing
- Tooling — blade and knife sizes matched to your material
- Units — metric and imperial dimensions on the same sheet
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-DSP-1215C · HTK-DSP-1820 · HTK-DSP-9020C
| Model / Stock No. | HTK-DSP-1215C | HTK-DSP-1820 | HTK-DSP-9020C |
|---|---|---|---|
| Table Length | 1200mm | 1800mm | 900mm |
| Table Width | 152mm | 204mm | 208mm |
| Aplainável Max. Planing Width | 150mm | Mesas 200mm | 204mm |
| Aplainável Max. Planing Depth | 5mm por passada | – | 3mm por passada |
| Head | 03 Facas - 150x20x2/2.5mm | – | 18 Pastilhas - 20x14x2.0mm |
| Roller Diameter | 82mm | – | 78mm |
| Dust Collector Outlet | 1800W (2,4CV) Monofásico 220V (10.000rpm) | 1x 4" (100mm) | 1x 2.5" (64mm) c/Saco Reservatório |
| Main Motor | 2.0 CV Monofásico 220V ou 2.0 CV Trifásico 220/380V (4.000rpm) | 3.0CV Monofásico 220V ou 3,0CV Trifásico 220/380V (4.000rpm) | 1.5 CV Monofásico 220V (4.000rpm) |
| Max. Useful Width | 317mm | – | 330mm |
| Pastilhado Head Pastilhado | 24 Pastilhas - 20x14x2.0mm | – | – |
| Maximum Planing Depth | – | 8mm por passada | 0,8/2,8 mm por passada |
| Number of Knives | – | 04 - 200x30x3mm | 03 - 330x15mm |
| Knife Roller Diameter | – | 94mm | – |
| Max. Passage Height | – | – | 152mm |
| Minimum Thickness x Length | – | – | 03 x 150 mm |
| Table Dimensions | – | – | Principal 330x240mm / 2 Extensões 330x200mm |
Specifications are published on the model spec sheet — request it and we'll send the full data including metric and imperial units.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
Get a quote
