PTS-6326
2 models · HTK-PLD-3012 · HTK-PLD-4012
- Built for — planers, moulders, sanders, presses and finishing
- Tooling — blade and knife sizes matched to your material
- Units — metric and imperial dimensions on the same sheet
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-PLD-3012 · HTK-PLD-4012
| Model / Stock No. | HTK-PLD-3012 | HTK-PLD-4012 |
|---|---|---|
| Max. Useful Width | 300mm | 400mm |
| Max. Passage Height | 120mm | 120mm |
| Minimum Thickness x Length | 10 x 200mm | 10 x 200 mm |
| Feed Speed | 11.5m/min 11.5m/min | 11.5 m/min |
| Number of Knives | 03 - 300x30x3mm | 03 - 400x30x3mm |
| Maximum Planing Depth | 4mm por passada | 4mm por passada |
| Main Motor | 3.0CV Monofásico 220V ou 3,0CV Trifásico 220/380V (4.000rpm) | 4.0 CV Trifásico 220/380V (4.000rpm) |
| Dust Collector Outlet | – | 1x 4" (100mm) |
Specifications are published on the model spec sheet — request it and we'll send the full data including metric and imperial units.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
Get a quote
