HTK-MM2218
5 models · HTK-TUP-2020 · HTK-TUP-2030 · HTK-TUP-2040 …
- Built for — planers, moulders, sanders, presses and finishing
- Tooling — blade and knife sizes matched to your material
- Units — metric and imperial dimensions on the same sheet
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-TUP-2020 · HTK-TUP-2030 · HTK-TUP-2040 · HTK-TUP-2050 · HTK-TUP-2218
| Model / Stock No. | HTK-TUP-2020 | HTK-TUP-2030 | HTK-TUP-2040 | HTK-TUP-2050 | HTK-TUP-2218 |
|---|---|---|---|---|---|
| Main Motor | 1,5kW | 2,2kW | 2,2kW | 3,0kW | 3,0kW |
| Lixa Sand Belt Size | 200 x 1520mm | 300 x 2230mm | 400 x 2630mm | 500 x 2830mm | 180 x 6800mm |
| Net Weight | 50kg | 80kg | 110kg | 130kg | 300kg |
| Lixamento Max. Sanding Width | 200mm | 300mm | 400mm | 500mm | – |
| Airbag Size of Airbag | ø100 x 200mm | ø100 x 200mm | ø100 x 200mm | ø100 x 20 mm | – |
| Spindle Speed | 1500rpm | 1324rpm | 1600rpm | 1600rpm | – |
| Lifting Stroke of Table | – | – | – | – | 0-750mm |
| Sand Roller Speed | – | – | – | – | 1420rpm |
| Lifting Motor | – | – | – | – | 0,75kW |
| Dust Collector | – | – | – | – | 1,1kW |
| Overall Dimensions | – | – | – | – | 3860 x 1530 x 1430mm |
Specifications are published on the model spec sheet — request it and we'll send the full data including metric and imperial units.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
Get a quote
