HTK-MB104 · HTK-MB105 · HTK-MB106 · HTK-MB107
6 models · HTK-PLD-104 · HTK-PLD-105 · HTK-PLD-106 …
- Built for — planers, moulders, sanders, presses and finishing
- Tooling — blade and knife sizes matched to your material
- Units — metric and imperial dimensions on the same sheet
- Shipping — container loading data supplied before you order
12
12-month warrantyFrame and head covered, parts available
24h
Reply within one working daySend photos or video, we diagnose with you
Specifications
HTK-PLD-104 · HTK-PLD-105 · HTK-PLD-106 · HTK-PLD-107 · HTK-PLD-203A · HTK-PLD-204A
| Model / Stock No. | HTK-PLD-104 | HTK-PLD-105 | HTK-PLD-106 | HTK-PLD-107 | HTK-PLD-203A | HTK-PLD-204A |
|---|---|---|---|---|---|---|
| Max. Planing Width | 400mm | 500mm | 600mm | 700mm | 300mm | 400mm |
| Max. Planing Thickness | 120mm | 120mm | 120mm | 120mm | – | – |
| Mín. Min. Planing Thickness | 10mm | 10mm | 10mm | 10mm | – | – |
| Max. Planing Depth | 4mm | 4mm | 4mm | 4mm | – | – |
| Mín. Min. Planning Length | 200mm | 200mm | 200mm | 200mm | 390mm | 390mm |
| Spindle Speed | 4000rpm | 4000rpm | 4000rpm | 4000rpm | 5000rpm | 5000rpm |
| Feeding Speed | 11.5 m/min | 11.5 m/min | 11.5 m/min | 11.5 m/min | 6 / 10 m/min | 6 / 10 m/min |
| Motor Power | 2,2kW | 3,0kW | 3,0kW | 3,0kW | 5,5kW | 7,5kW |
| Net Weight | 170kg | 190kg | 220kg | 250kg | 510kg | 580kg |
| Planing Thickness | – | – | – | – | 8 —120mm | 8—120mm |
| Max. Top Cutter Planing Depth | – | – | – | – | 4mm | 4mm |
| Max. Bottom Cutter Planing Depth | – | – | – | – | 2mm | 2mm |
Specifications are published on the model spec sheet — request it and we'll send the full data including metric and imperial units.
Not sure this is the right model?
Send us your material and sizes — we'll confirm the specification, tooling and container loading.
